R454B Refrigerant
A lower Global Warming Potential (GWP), eco-friendly option that meets updated refrigerant guidelines while maintaining high efficiency.
SmartHQ™ Home
Built-In WiFi allows you to monitor status, adjust temperature, and set cooling and heating schedules from anywhere using your smartphone
Mounting Template/Plate
A convenient printed cardboard template and mounting plate enable accurate, single-person installation, ensuring correct positioning of the lineset and drain opening.
Easy Installation Clip
The built-in bracket provides extra room for easier installation and service.
2-Way Piping Drain
Flexible right or left side condensation drain options simplify installation (right side only with RDS installed).
Warm Start
Ensures the fan does not blow cold air during heating mode startup.
Auto Louver
An auto louver adjusts airflow upward when cooling and downward when heating to maximize comfort and minimize hot and cold spots.
Indoor Air Filter
The easily removable and cleanable indoor air filter reduces maintenance time, ensuring cleaner air and longer-lasting efficiency.
Ten-Year Limited Warranty
Double the standard five-year limited warranty simply by registering the unit, giving your homeowners additional peace of mind. See warranty documentation for complete details.
See specification guide for full heating, cooling, and system details.
| APPEARANCE | |
| Color Appearance | White |
| FEATURES | |
| Connected Capabilities | Amazon Alexa Google Home |
| Drainpipe Size (in) | 5/8 |
| Fan Speed Stages | 5 + Auto |
| Fan Speeds CFM | 360/300/272/240/210 |
| Indoor Sound Level | 44/39/36/33/27 |
| Outdoor Model to Complete Multi Zone System | Select Multi Zone Outdoor Units |
| Product Type | Single Zone Multi Zone |
| Style | Highwall |
| Unit Type | Indoor |
| WiFi Connect | Built-In SmartHQ Home Built-In |
| POWER / RATINGS | |
| Cooling Rated Capacity BTU/Hr | 12,000 |
| Voltage/Hertz/Phase | 208-230/60/1 |
| WARRANTY | |
| Parts Warranty | Limited 5-Year Parts and Compressor 10-Year Limited Parts and Compressor Warranty with Registration See warranty documentation for complete information |
| WEIGHTS & DIMENSIONS | |
| Approximate Shipping Weight | 26.9193 lb |
| Liquid O.D. Refrigerant Line | 1/4″ |
| Net Weight | 21.84435 lb |
| Overall Depth | 7 3/4″ |
| Overall Height | 11 7/8″ |
| Overall Width | 34 1/4″ |
| Suction O.D. Refrigerant Line | 3/8″ |
