| APPEARANCE | |
| Color Appearance | Gray |
| FEATURES | |
| Base Pan Heater | Yes |
| Compatible Indoor Models | GS09WP2BEA US09FB2BEA US09CB2BEA US09MB2BEA |
| Connections | Flare |
| Factory Charge (ounces) | 46.6 |
| Maximum Fuse Size A | 20 |
| Maximum Height (Ft/m) | 33/10 |
| Maximum Line Length (Ft/M) | 66/20 |
| Outdoor Noise Level | 54 |
| Product Type | Single Zone |
| Rotary Compressor | DC Inverter Driven Rotary |
| Series | Endure |
| Style | Outdoor |
| System | 9K Endure |
| Temperature Range – Heating Mode | -31-75°F (-35-24°C) |
| Unit Type | Outdoor |
| POWER / RATINGS | |
| Cooling Rated Capacity BTU/Hr | 9,000 |
| Minimum Circuit Amp | 13 |
| Voltage/Hertz/Phase | 208-230/60/1 |
| WARRANTY | |
| Parts Warranty | Limited 5-Year Parts and Compressor 10-Year Limited Parts and Compressor Warranty with Registration See warranty documentation for complete information |
| WEIGHTS & DIMENSIONS | |
| Approximate Shipping Weight | 96.86535 lb |
| Liquid O.D. Refrigerant Line | 1/4″ |
| Net Weight | 83.4057 lb |
| Overall Depth | 12 |
| Overall Height | 25 1/4 |
| Overall Width | 35 3/8 |
| Suction O.D. Refrigerant Line | 3/8″ |
